```JSON
{
"data": {
"id": "738137187639794****",
"conversation_id": "748348012449138***",
"bot_id": "22248012449138***",
"created_at": 1710348675,
"completed_at": 1710348675,
"last_error": null,
"meta_data": {},
"status": "completed",
"usage": {
"token_count": 3397,
"output_tokens": 1173,
"input_tokens": 2224
}
},
"code": 0,
"msg": ""
}
```
```JSON
{
"code": 0,
"data": {
"bot_id": "737282596785517****",
"completed_at": 1717513285,
"conversation_id": "737666232053956****",
"created_at": 1717513283,
// 在 chat 事件里，data 字段中的 id 为 Chat ID，即会话 ID。
"id": "737666232053959****",
"required_action": {
"submit_tool_outputs": {
"tool_calls": [
{
"function": {
"arguments": "{\"location\":\"南京\",\"type\":0}",
"name": "local_data_assistant"
},
"id": "BUJJF0dAQ0NAEBVeQkVKEV5HFURFXhFCEhFeFxdHShcSQEtFSxYRSUI=",
"type": "function"
}
]
},
"type": "submit_tool_outputs"
},
"status": "requires_action"
},
"msg": ""
}
```
```JSON
# chat - 开始
event: conversation.chat.created
// 在 chat 事件里，data 字段中的 id 为 Chat ID，即会话 ID。
data: {"id": "123", "conversation_id":"123", "bot_id":"222", "created_at":1710348675,compleated_at:null, "last_error": null, "meta_data": {}, "status": "created","usage":null}
# chat - 处理中
event: conversation.chat.in_progress
data: {"id": "123", "conversation_id":"123", "bot_id":"222", "created_at":1710348675, compleated_at: null, "last_error": null,"meta_data": {}, "status": "in_progress","usage":null}
# MESSAGE - 知识库召回
event: conversation.message.completed
data: {"id": "msg_001", "role":"assistant","type":"knowledge","content":"---\nrecall slice 1:xxxxxxx\n","content_type":"text","chat_id": "123", "conversation_id":"123", "bot_id":"222"}
# MESSAGE - function_call
event: conversation.message.completed
data: {"id": "msg_002", "role":"assistant","type":"function_call","content":"{\"name\":\"toutiaosousuo-search\",\"arguments\":{\"cursor\":0,\"input_query\":\"今天的体育新闻\",\"plugin_id\":7281192623887548473,\"api_id\":7288907006982012986,\"plugin_type\":1","content_type":"text","chat_id": "123", "conversation_id":"123", "bot_id":"222"}
# MESSAGE - toolOutput
event: conversation.message.completed
data: {"id": "msg_003", "role":"assistant","type":"tool_output","content":"........","content_type":"card","chat_id": "123", "conversation_id":"123", "bot_id":"222"}
# MESSAGE - answer is card
event: conversation.message.completed
data: {"id": "msg_004", "role":"assistant","type":"answer","content":"{{card_json}}","content_type":"card","chat_id": "123", "conversation_id":"123", "bot_id":"222"}
# MESSAGE - answer is normal text
event: conversation.message.delta
data:{"id": "msg_005", "role":"assistant","type":"answer","content":"以下","content_type":"text","chat_id": "123", "conversation_id":"123", "bot_id":"222"}
event: conversation.message.delta
data:{"id": "msg_005", "role":"assistant","type":"answer","content":"是","content_type":"text","chat_id": "123", "conversation_id":"123", "bot_id":"222"}
...... {{ N 个 delta 消息包}} ......
event: conversation.message.completed
data:{"id": "msg_005", "role":"assistant","type":"answer","content":"{{msg_005 完整的结果。即之前所有 msg_005 delta 内容拼接的结果}}","content_type":"text","chat_id": "123", "conversation_id":"123", "bot_id":"222"}
# MESSAGE - 多 answer 的情况,会继续有 message.delta
event: conversation.message.delta
data:{"id": "msg_006", "role":"assistant","type":"answer","content":"你好你好","content_type":"text","chat_id": "123", "conversation_id":"123", "bot_id":"222"}
...... {{ N 个 delta 消息包}} ......
event: conversation.message.completed
data:{"id": "msg_006", "role":"assistant","type":"answer","content":"{{msg_006 完整的结果。即之前所有 msg_006 delta 内容拼接的结果}}","content_type":"text","chat_id": "123", "conversation_id":"123", "bot_id":"222"}
# MESSAGE - Verbose （流式 plugin, 多 answer 结束，Multi-agent 跳转等场景）
event: conversation.message.completed
data:{"id": "msg_007", "role":"assistant","type":"verbose","content":"{\"msg_type\":\"generate_answer_finish\",\"data\":\"\"}","content_type":"text","chat_id": "123", "conversation_id":"123", "bot_id":"222"}
# MESSAGE - suggestion
event: conversation.message.completed
data: {"id": "msg_008", "role":"assistant","type":"follow_up","content":"朗尼克的报价是否会成功？","content_type":"text","chat_id": "123", "conversation_id":"123", "bot_id":"222"}
event: conversation.message.completed
data: {"id": "msg_009", "role":"assistant","type":"follow_up","content":"中国足球能否出现？","content_type":"text","chat_id": "123", "conversation_id":"123", "bot_id":"222"}
event: conversation.message.completed
data: {"id": "msg_010", "role":"assistant","type":"follow_up","content":"羽毛球种子选手都有谁？","content_type":"text","chat_id": "123", "conversation_id":"123", "bot_id":"222"}
# chat - 完成
event: conversation.chat.completed （chat完成）
data: {"id": "123", "chat_id": "123", "conversation_id":"123", "bot_id":"222", "created_at":1710348675, compleated_at:1710348675, "last_error":null, "meta_data": {}, "status": "compleated", "usage":{"token_count":3397,"output_tokens":1173,"input_tokens":2224}}
event: done （stream流结束）
data: [DONE]
# chat - 失败
event: conversation.chat.failed
data: {
"code":701231,
"msg":"error"
}
```
## 错误码
如果成功调用扣子编程的 API，返回信息中 code 字段为 0。如果状态码为其他值，则表示接口调用失败。此时 msg 字段中包含详细错误信息，你可以参考[错误码](https://docs.coze.cn/developer_guides/coze_error_codes)文档查看对应的解决方法。
