将 AI 编程生成的工作流部署为 API 服务后,你可以通过 HTTP 请求在自己的应用或网页中调用该工作流,从而集成对应的 AI 能力。
已将 AI 编程生成的智能体部署为 API 服务。具体可参考部署智能体。
获取该服务的 API 访问地址、请求Header、请求参数等详细信息。
你需要创建 API Token,调用 API 时需要使用 API Token 进行身份验证。你需要将创建的 API Token 包含在请求头的 Authorization 参数中。
说明
|
API 接口 |
请求地址 |
适用场景 |
|---|---|---|
|
执行智能体 |
|
适用于需要直接调用智能体,并通过 SSE 事件流持续接收智能体回复、工具调用等事件的场景。 |
|
异步执行智能体 |
|
适用于执行时间较长(24小时以内)、不需要在当前请求中立即获取结果的场景。调用后会先返回异步任务 ID。 |
|
查询异步执行任务状态 |
|
用于根据异步任务 ID 查询任务状态、执行结果或错误信息。 |
智能体 API 的请求体通常包含智能体输入内容、请求类型、会话 ID 和项目 ID。不同智能体的可用输入内容可能不同,请以部署页面展示的参数说明和调用示例为准。
公共请求参数说明如下:
|
字段 |
类型 |
描述 |
|---|---|---|
|
content |
object |
本次调用输入给智能体的内容。 |
|
content.query.prompt |
array |
用户输入内容列表。文本输入时,元素的 type 为 text。 |
|
content.query.prompt[].content.text |
string |
用户输入的文本内容。 |
|
type |
string |
请求类型。文本问答场景通常为 query。 |
|
session_id |
string |
会话 ID。由开发者自行定义,相同会话 ID 可用于关联多轮对话上下文。 |
|
project_id |
int |
项目 ID。请使用部署页面调用示例中的项目 ID。 |
{
"content": {
"query": {
"prompt": [
{
"type": "text",
"content": {
"text": "今天天气真好,我们去爬山吧"
}
}
]
}
},
"type": "query",
"session_id": "B683KwyyyPEj3cbMxvuIx",
"project_id": 7647467737832407091
}
如果需要让智能体识别或分析图片、视频等文件内容,请使用 upload_file 类型传入文件 URL。AI 编程项目中不兼容低代码 API 文档中的上传文件等 API 。
{
"content": {
"query": {
"prompt": [
{
"type": "text",
"content": {
"text": "请分析这张图片的内容"
}
},
{
"type": "upload_file",
"content": {
"upload_file": {
"url": "https://example.com/demo.awebp",
"file_name": "demo.awebp"
}
}
}
]
}
},
"type": "query",
"session_id": "B683KwyyyPEj3cbMxvuIx",
"project_id": 764746773783240****
}
调用智能体的 API 是一个流式响应 API。调用该 API 时,服务端不会一次性发送所有数据,而是以数据流的形式逐条发送数据给客户端,数据流中包含智能体执行过程中触发的各种事件,直至处理完毕或处理中断。
curl --location --request POST 'https://<your_domain>/stream_run' \
--header 'Authorization: Bearer <YOUR_API_TOKEN>' \
--header 'Content-Type: application/json' \
--data '{
"content": {
"query": {
"prompt": [
{
"type": "text",
"content": {
"text": "今天天气真好,我们去爬山吧"
}
}
]
}
},
"type": "query",
"session_id": "B683KwyyyPEj3cbMxvuIx",
"project_id": 764746773783240****
}'
其中,请将:
event: message
data: {"type":"message_start","session_id":"kWzXiLlm2kZjWZaEB3Kn0","query_msg_id":"","reply_id":"6b7a19b7-8d5e-4925-9ff0-ec5558740e0a","msg_id":"4a4d34bd-7772-40e5-8f41-a45670cbd897","sequence_id":1,"finish":true,"content":{"answer":null,"thinking":null,"tool_request":null,"tool_response":null,"error":null,"message_start":{"local_msg_id":"","msg_id":"","execute_id":"63f6f0ee-7a76-4cb1-9ced-79ea35036556"},"message_end":null},"log_id":"20260604200843BED3BB46C848623AC0D8"}
event: message
data: {"type":"answer","session_id":"kWzXiLlm2kZjWZaEB3Kn0","query_msg_id":"","reply_id":"6b7a19b7-8d5e-4925-9ff0-ec5558740e0a","msg_id":"8127b0e3-e5f6-4c79-a60e-ff4559f8fefa","sequence_id":2,"finish":false,"content":{"answer":"你","thinking":null,"tool_request":null,"tool_response":null,"error":null,"message_start":null,"message_end":null},"log_id":"20260604200843BED3BB46C848623AC0D8"}
event: message
data: {"type":"answer","session_id":"kWzXiLlm2kZjWZaEB3Kn0","query_msg_id":"","reply_id":"6b7a19b7-8d5e-4925-9ff0-ec5558740e0a","msg_id":"8127b0e3-e5f6-4c79-a60e-ff4559f8fefa","sequence_id":3,"finish":false,"content":{"answer":"还","thinking":null,"tool_request":null,"tool_response":null,"error":null,"message_start":null,"message_end":null},"log_id":"20260604200843BED3BB46C848623AC0D8"}
event: message
data: {"type":"answer","session_id":"kWzXiLlm2kZjWZaEB3Kn0","query_msg_id":"","reply_id":"6b7a19b7-8d5e-4925-9ff0-ec5558740e0a","msg_id":"8127b0e3-e5f6-4c79-a60e-ff4559f8fefa","sequence_id":28,"finish":false,"content":{"answer":"✨","thinking":null,"tool_request":null,"tool_response":null,"error":null,"message_start":null,"message_end":null},"log_id":"20260604200843BED3BB46C848623AC0D8"}
event: message
data: {"type":"answer","session_id":"kWzXiLlm2kZjWZaEB3Kn0","query_msg_id":"","reply_id":"6b7a19b7-8d5e-4925-9ff0-ec5558740e0a","msg_id":"8127b0e3-e5f6-4c79-a60e-ff4559f8fefa","sequence_id":29,"finish":true,"content":{"answer":"","thinking":null,"tool_request":null,"tool_response":null,"error":null,"message_start":null,"message_end":null},"log_id":"20260604200843BED3BB46C848623AC0D8"}
event: message
data: {"type":"message_end","session_id":"kWzXiLlm2kZjWZaEB3Kn0","query_msg_id":"","reply_id":"6b7a19b7-8d5e-4925-9ff0-ec5558740e0a","msg_id":"16117493-add0-4eb6-8188-9de49fe0b62c","sequence_id":30,"finish":true,"content":{"answer":null,"thinking":null,"tool_request":null,"tool_response":null,"error":null,"message_start":null,"message_end":{"code":"0","message":"","token_cost":{"input_tokens":0,"output_tokens":0,"total_tokens":0},"time_cost_ms":2734}},"log_id":"20260604200843BED3BB46C848623AC0D8"}
|
字段 |
类型 |
描述 |
|---|---|---|
|
event |
string |
SSE 事件类型,一般为 message。 |
|
data |
object |
SSE 事件内容。不同 data.type 对应不同事件结构。 |
常见事件说明如下:
|
事件 |
说明 |
|---|---|
|
message_start |
智能体开始处理本次消息。 |
|
answer |
智能体回复内容。回复可能会拆成多条 answer 事件返回,调用端需要按 sequence_id 顺序拼接 data.content.answer。当 finish 为 true 时,表示回复内容片段返回结束。 |
|
tool_request |
智能体发起工具调用请求,具体内容可从 data.content.tool_request 获取。 |
|
tool_response |
工具调用结果,具体内容可从 data.content.tool_response 获取。 |
|
message_end |
本次智能体回复结束。结束信息可从 data.content.message_end 获取,例如状态码、错误消息、Token 消耗和耗时。 |
|
error |
执行过程中出现错误。 |
异步执行接口会创建一个异步执行任务,并立即返回任务信息。调用端不需要一直保持连接,可以后续通过任务 ID 查询执行状态和结果。
curl --location --request POST 'https://<your_domain>/async_run' \
--header 'Authorization: Bearer <YOUR_API_TOKEN>' \
--header 'Content-Type: application/json' \
--data '{
"content": {
"query": {
"prompt": [
{
"type": "text",
"content": {
"text": ""
}
}
]
}
},
"type": "query",
"session_id": "B683KwyyyPEj3cbMxvuIx",
"project_id": 7647467737832407091
}'
其中,请将:
{
"task_id": "6a5fa5ade320435a9c44fd5052a3b2a0",
"status": "pending",
"created_at": "2026-05-25T15:16:10.151364+08:00",
"deadline": "2026-05-26T15:16:10.151364+08:00"
}
|
字段 |
类型 |
描述 |
|---|---|---|
|
task_id |
string |
异步执行任务 ID。后续查询任务状态时需要使用该 ID。 |
|
status |
string |
异步执行任务状态,枚举值包括 pending、running、completed、failed、timeout。 |
|
created_at |
string |
异步执行任务创建时间,使用 ISO 时间格式。 |
|
deadline |
string |
异步执行任务截止时间,使用 ISO 时间格式。任务的最长运行时间以该字段为准。 |
调用异步执行接口后,你可以使用 task_id 查询任务状态。任务完成后,接口会返回执行结果;任务失败时,接口会返回错误信息。
curl --location --request GET 'https://<your_domain>/task/{task_id}' \
--header 'Authorization: Bearer <YOUR_API_TOKEN>'
其中,请将 {task_id} 替换为调用 /async_run 后返回的任务 ID。
{
"status": "completed",
"result": "{\"answer\":\"今天天气确实不错,很适合去爬山。\"}",
"error": null
}
|
字段 |
类型 |
描述 |
|---|---|---|
|
status |
string |
异步执行任务状态,可能值包括 pending、running、completed、failed、timeout。 |
|
result |
string |
智能体执行结果。任务完成后返回,内容结构以实际智能体输出为准。 |
|
error |
string |
错误信息。任务执行成功时通常为 null。 |
|
状态 |
说明 |
|---|---|
|
pending |
任务已创建,等待被执行。 |
|
running |
任务正在执行中。 |
|
completed |
任务执行完成。 |
|
failed |
任务执行失败。 |
|
timeout |
任务执行超时。 |
